StrongArm™ SVR303

StrongArm SVR303

ANSI MH30.3 tested and approved, the StrongArm™ SVR303 is a low-profile, non-impact design with a rotating arm that seeks a trailer's ICC bar via a patented, switchless technology.

Once engaged, it uses 35,000lbs (15,909kgs) of restraining force to secure the truck to the dock. Dual-acting hydraulic cylinders prevent lock-up and release problems.

The Intelligent Positioning System (IPS) constantly communicates the location of the restraint arm via a network that enables the integrated lights communication system to accurately display safety conditions at the loading dock.

innovative design and operation

  • A profile that is one of the lowest in the industry (8”/ 203mm), significantly reducing the risk of impact damage
  • Vertical restraining range from 8” to 26” (203mm to 660mm) above grade with minimum 4” (102mm) contact space required
  • Horizontal restraining range up to 13” (330mm) from the face of the dock
  • A high-visibility barrier-style restraint arm that uses passive engagement keep an ICC bar secured, resulting in less wear and tear and a lower lifetime cost of ownership
  • An Intelligent Positioning System (IPS) that does not use mechanical switches and sensors to detect the ICC bar, resulting in more dependable performance
  • PosiLock™ dual mechanical lock system that guards against accidental trailer separation and ensures safe, reliable performance during all stages of the engagement cycle
  • Submersible: NEMA6 IPS sensor and double-acting hydraulic cylinders keep the unit operating safely and efficiently during wet or flooded conditions
  • Restraint arm dislodges or breaks apart obstacles that prevent it from properly parking

INTELLIGENT TOUCH CONTROLS

  • The Blue Genius™ Gold Series II Touch Control Panel features include an LCD menu screen, function buttons and a flat surface keypad with unique touch sensors
  • Interior and exterior LED lights keep drivers and warehouse personnel advised of safety conditions
  • Audible alarm built into the control panel alerts the dock attendant to potentially unsafe conditions, such as broken or missing ICC bars
  • Audible touch buttons and keypad provide instant sound feedback to user input

Video

The StrongArm SVR303 hydraulic vehicle restraint is fully submersible: NEMA6 IPS sensor and double-acting hydraulic cylinders keep the unit operating safely and efficiently during wet or flooded conditions.


Related Links

RECOMMENDED APPLICATIONS

  • High-volume cargo handling applications
  • Locations that frequently experience wet or flooded conditions

AVAILABLE OPTIONS

  • Pit-mounted hydraulic powerpack
  • Extension plates
  • Zinc finish or hot-dipped galvanizing for extension plates
  • Weather seal kit
